BENINCA - 24VDC GEARMOTOR FOR SLIDING GATES FOR COMMERCIAL USE UP TO 1500KG OF WEIGHT
- IRREVERSIBLE 24VDC OPERATOR EQUIPPED WITH A CONTROL UNIT WITH BUILT-IN RECEIVER AND VIRTUAL ENCODER, FOR INTENSIVE USE
- THE PRESENCE OF THE VIRTUAL ENCODER ALLOWS OPTIMAL MANAGEMENT OF SLOWDOWNS
- GUARANTEED OPERATION EVEN IN THE ABSENCE OF ELECTRICAL POWER VIA BATTERIES THAT CAN BE PERFECTLY INTEGRATED IN THE MOTOR (NOT INCLUDED)
- ANTI-CRUSHING SYSTEM WITH AMPEROMETRIC DETECTION
- FOUNDATION TEMPLATE WITH ANCHOR BOLTS INCLUDED
- VERSION WITH MAGNETIC LIMIT SWITCHES
GEARMOTOR FOR SLIDING GATES
BULL1524.SE.S 959002904
TECHNICAL DETAILS:
Power supply: 85 ÷ 265 Vac (50-60Hz)
Motor supply: 23 Vdc
Max absorbed current: 1,7 A
Max Thrust: 944 N
Opening speed: 11,7 m/min
Duty cycle: intensive use
Protection level: IP44
Magnetic limit switches: YES
Operating temperature: -20°C /+50°C
