BENINCA - HEAVY-DUTY 24 VDC BARRIER WITH INTEGRATED CONTROL UNIT, ENCODER AND BATTERY CHARGER
- FOR PASSAGES UP TO 5M
- SWITCHING POWER SUPPLY 100÷250 VAC ALLOWING LOW POWER CONSUMPTION AND LONG ACTUATOR LIFE
- EQUIPPED WITH A BUILT-IN ABSOLUTE ENCODER TO ALLOW MAXIMUM PRECISION IN SLOWDOWNS AND ADVANCED CONTROL OVER ROD MOVEMENT
- INTEGRATED STC SYSTEM FOR PUNCTUAL TORQUE CALCULATION
- QUICK CONNECTION POSSIBILITY FOR OPPOSING ROD OPERATION THANKS TO SIS ACCESSORY BOARD
- INTEGRATED FLASHING LIGHT (REQUIRES ACCESSORY CARD EVA.LAMP)
FOUNDATION PLATE NOT INCLUDED
BENINCA - EVA.5
TECHNICAL FEATURES:MAINS POWER SUPPLY: 100 ÷ 250 VAC (50-60HZ)
MOTOR POWER SUPPLY: 24VDC
MAXIMUM CURRENT ABSORBED: 3.1 / 1.6 A
OPENING TIME: 3.5’ ÷ 6’
INDEX OF PROTECTION: IP44
LUBRICATION: GREASE
OPERATING TEMPERATURE: -20°C /+50°C
PASSAGE LENGTH: 5 M
