beninca electronic interface board q.be mqtt 976007253
£420.00 £260.40 |
|---|
BENINCA - Q.BE MQTT ELECTRONIC INTERFACE BOARD
MQTT IS A LIGHTWEIGHT COMMUNICATION PROTOCOL BASED ON TCP/IP, DESIGNED FOR THE EFFICIENT TRANSMISSION OF REAL-TIME DATA BETWEEN IoT DEVICES AND MONITORING SYSTEMS.
IT ENABLES A SIMPLE, RELIABLE AND SCALABLE EXCHANGE OF INFORMATION, EVEN ON LOW-BANDWIDTH NETWORKS. IT IS PARTICULARLY SUITABLE FOR APPLICATIONS IN THE FIELDS OF HOME AUTOMATION, INDUSTRY AND SMART CITIES.
- AN ELECTRONIC BOARD THAT ENABLES BENINCÀ AUTOMATION SYSTEMS TO BE EASILY INTEGRATED WITH OTHER SYSTEMS USING THE MQTT COMMUNICATION PROTOCOL
- EQUIPPED WITH A LOCAL WEB SERVER, IT ALLOWS COMMANDS TO BE SENT DIRECTLY VIA A BROWSER, WITHOUT THE NEED TO GO THROUGH AN EXTERNAL SERVER
- IT FEATURES A SERIAL INTERFACE FOR COMPATIBLE BENINCÀ CONTROL UNITS AND AN ETHERNET PORT FOR CONNECTION TO A PC OR NETWORK
- IT IS POSSIBLE TO CONTROL THE AUTOMATION SYSTEM, CHECK THE STATUS OF THE INPUTS AND ANY ALARMS, OR SIMPLY ACCESS STATISTICAL DATA (E.G. THE NUMBER OF OPERATIONS FOR SCHEDULED MAINTENANCE MANAGEMENT)
MQTT IS A LIGHTWEIGHT COMMUNICATION PROTOCOL BASED ON TCP/IP, DESIGNED FOR THE EFFICIENT TRANSMISSION OF REAL-TIME DATA BETWEEN IoT DEVICES AND MONITORING SYSTEMS.
IT ENABLES A SIMPLE, RELIABLE AND SCALABLE EXCHANGE OF INFORMATION, EVEN ON LOW-BANDWIDTH NETWORKS. IT IS PARTICULARLY SUITABLE FOR APPLICATIONS IN THE FIELDS OF HOME AUTOMATION, INDUSTRY AND SMART CITIES.
- AN ELECTRONIC BOARD THAT ENABLES BENINCÀ AUTOMATION SYSTEMS TO BE EASILY INTEGRATED WITH OTHER SYSTEMS USING THE MQTT COMMUNICATION PROTOCOL
- EQUIPPED WITH A LOCAL WEB SERVER, IT ALLOWS COMMANDS TO BE SENT DIRECTLY VIA A BROWSER, WITHOUT THE NEED TO GO THROUGH AN EXTERNAL SERVER
- IT FEATURES A SERIAL INTERFACE FOR COMPATIBLE BENINCÀ CONTROL UNITS AND AN ETHERNET PORT FOR CONNECTION TO A PC OR NETWORK
- IT IS POSSIBLE TO CONTROL THE AUTOMATION SYSTEM, CHECK THE STATUS OF THE INPUTS AND ANY ALARMS, OR SIMPLY ACCESS STATISTICAL DATA (E.G. THE NUMBER OF OPERATIONS FOR SCHEDULED MAINTENANCE MANAGEMENT)
ELECTRONIC INTERFACE BOARD
Q.BE MQTT 976007253
Q.BE MQTT 976007253
TECHNICAL SPECIFICATIONS:
- Power supply via EXP directly from the automation system or 8–30 Vdc – 10–30 Vac
- Instantaneous current draw = 100 mA (depending on configuration and setup)
- Freescale™ i.MX6 Family CPUs, based on ARM Cortex-A9 processors: i.MX6ULL up to 528 MHz
- Instantaneous current draw = 100 mA (depending on configuration and setup)
- Freescale™ i.MX6 Family CPUs, based on ARM Cortex-A9 processors: i.MX6ULL up to 528 MHz
- 256MB DDR3L RAM sold on board
- 8GB eMMC flash sold on board, expandable via an internal MicroSD slot (optional connector)
- Operating system: Linux File System – YOCTO – Pyro, Linux kernel var-som-mx6ul 4.9.88
- 8GB eMMC flash sold on board, expandable via an internal MicroSD slot (optional connector)
- Operating system: Linux File System – YOCTO – Pyro, Linux kernel var-som-mx6ul 4.9.88
- Main 10/100 Ethernet interface
- Power-on LED and diagnostic and status LEDs
- Internal RTC clock with dedicated backup battery
- Operating temperature: 0°C to +70°C
- Power-on LED and diagnostic and status LEDs
- Internal RTC clock with dedicated backup battery
- Operating temperature: 0°C to +70°C
