BENINCA - IRREVERSIBLE ELECTROMECHANICAL GEARMOTOR, FOR LARGE SECTIONAL DOORS, ROLLING DOORS AND UNBALANCED SHUTTERS, INDUSTRIAL USE
- EQUIPPED WITH MANUAL CHAIN OPERATION AND RELEASE, IN CASE OF EMERGENCY
- VENTILATED ELECTRIC MOTOR IDEAL FOR INTENSIVE USE, EQUIPPED WITH AN ELECTRIC BRAKE
- TWO ACCESSORIES ARE AVAILABLE FOR THE CHAIN TRANSMISSION WITH REDUCTION RATIO 1:1 (OFF-AXIS MOTOR INSTALLATION) OR 1:1.8 (TORQUE OR SPEED MULTIPLIER)
- MAXIMUM SAFETY IS GUARANTEED EVEN DURING MANUAL OPERATION, THANKS TO A MICRO-SWITCH THAT INTERRUPTS THE MOTOR POWER SUPPLY
- THE OIL-BATH REDUCTION GEARS WITH HARDENED STEEL SCREW AND BRONZE GEAR GUARANTEE HIGH PERFORMANCE, MAXIMUM RELIABILITY AND SILENT OPERATION
- 4 MICROMETRIC ADJUSTMENT LIMIT SWITCHES
GEARMOTOR FOR INDUSTRIAL SECTIONAL DOORS
VN.MT40V 9590377
TECHNICAL DETAILS:
MAINS SUPPLY: 400 Vac (50-60Hz)
MOTOR POWER SUPPLY: 400 Vac
MAXIMUM ABSORBED CURRENT: 2,2 A
MAX DRIVE TORQUE: 340 Nm
MAX OUTPUT ROTATIONS: 38
OUTPUT SPEED: 24 r.p.m.
SHAFT BORE: 1” (25,4 mm)
LIMIT SWITCH REDUCTION RATIO: 1/40
WORKING CYCLE: uso intensivo
INDEX OF PROTECTION: IP40
OPERATING TEMPERATURE: -20°C /+50°C
LUBRICATION: OLIO
