BENINCA - ORIGINAL SPARE PART
INTERNAL CONTROL UNIT FOR 1 ACTUATOR SERIES BULL624/1224 TURBO
- MOTOR POWER SUPPLY 24 Vdc / 20 A
- CONTROL UNIT POWER SUPPLY 115 OR 230 VAC (SELECTABLE) - 50/60HZ
- INTEGRATED RADIO RECEIVER 433.92MHZ 512 CODES AND ARC RADIO CODING
- AUTOMATIC, SEMI-AUTOMATIC AND DEAD MAN OPERATION LOGIC
- INPUTS STOP, OPEN, CLOSE, STEP, PHOTOCELL INPUT (PHO) PROGRAMMABLE ACTIVE ON BOTH OPENING AND CLOSING OR ACTIVE ONLY ON CLOSING
- INPUT FOR SENSITIVE EDGE N.C. OR 8K2
- TWO OUTPUTS CONFIGURABLE AS OPEN GATE WARNING LIGHT, COURTESY LIGHT, ZONE LIGHT, SECOND RADIO CHANNEL, PHOTOCELL TEST, FLASHING LIGHT, ALARM CONTACT
- PREPARED FOR MANAGEMENT, CONFIGURATION, DIAGNOSTICS AND FIRMWARE UPDATE THROUGH THE BEUP APP, VIA PRO.UP ACCESSORY
- POSSIBILITY OF PARAMETER CONFIGURATION AND RADIO CONTROL MANAGEMENT WITH ADVANTOUCH SYSTEM
- INTEGRATED CHARGER, COMPATIBLE WITH BATTERIES MOD. DA.BT2/DA.BT6
- NOT INCLUDING COVER AND FIXING PLASTICS.
968602602
BENINCA - CP.B24 TURBO
