came ati 230v gearmotor 001a3000 a3000

SKU: 001A3000

£606.00  £339.36VAT INCLUDED

CAME - IRREVERSIBLE GEARMOTOR FOR SWING GATES UP TO 3 METERS PER LEAF

LEAF OPENING TIME AT 90°: 19 - 32 SECONDS
CURRENT DETECTION OF THE OBSTACLE
SOLUTION FOR RESIDENTIAL AND CONDOMINIUM APPLICATIONS
POWER SUPPLY: 230V AC


EQUIPPED WITH ONE MICRO LIMIT SWITCH (ON OPENING)






001A3000       A3000
230V AC



Type
A3000/A3100
A5000/A5100
A3006/3106
A5006/A5106
A3024N
A5024N
Protection level
IP44
Power supply
230V 50/60 Hz
230V 50/60 Hz/24V D.C.
Motor power supply
230V 50/60 Hz
24V D.C.
Absorption
1,2A
10A max
Nominal power
150W
120W
Duty cycle
50%
intensive duty
Thrust
400-3000N
Motor's heat protection
150°C

Maneuvering time (90°)
19-32s
28-45s
adjustable
Operating temperature
-20 °C min +55 °C max



Complementary accessories (not included):
- ZA3P: Multifunctional control panel with built-in radio decoding
- LOCK81: Single cylinder electric lock
- LOCK82: Double cylinder electric lock
- D001: Lock cylinder with din key
- H3000: Case for remote release with customized key, pull-cord handle and control button. Cord length L=5m

  • Brand: CAME
