CARDIN - SELF-LOCKING ACTUATOR WITH ENCODER. SUPPLIED WITH MECHANICAL LIMIT SWITCHES, FOR LEAVES OF MAX 5MT AND 300KG
THE REDUCTION SYSTEM GUARANTEES THE LOCKING OF THE LEAF WHEN CLOSING
CARDIN ELECTRONIC PROGRAMMER TO BE ORDERED SEPARATELY T600
GEARMOTOR FOR SWING GATES
BLADE5
230V
TECHNICAL FEATURES:
POWER SUPPLY: 230Vac
ABSORPTION: 1,6A
ABSORBED POWER: 370W
PUSH: 2200N
SCREW STROKE: 500mm
WORKING INTERMITTENCE: 30%
90° OPENING TIME: 28,5sec
MAXIMUM OPENING: 110°
DEGREE OF PROTECTION: IP44
