CARDIN - SELF-LOCKING ACTUATOR WITH ENCODER. SUPPLIED WITH MECHANICAL LIMIT SWITCHES, FOR LEAVES OF UP TO 3 M AND 250 KG
THE REDUCTION SYSTEM ENSURES THAT THE LEAF IS LOCKED WHEN CLOSING
CARDIN ELECTRONIC PROGRAMMER TO BE ORDERED SEPARATELY T624
GEARMOTOR FOR SWING GATES
BLADE324
24V
TECHNICAL FEATURES:
POWER SUPPLY: 24Vdc
ABSORPTION: 2A
ABSORBED POWER: 60W
PUSH: 1900N
SCREW COURSE: 350mm
WORKING INTERMITTANCE: 70%
OPENING TIME 90°: 15sec
MAXIMUM OPENING: 110°
DEGREE OF PROTECTION: IP44
