CARDIN - REVERSIBLE ACTUATOR WITH ENCODER. SUPPLIED WITH MECHANICAL LIMIT SWITCHES, FOR LEAVES OF MAX. 3 M AND 250 KG
ELECTROMECHANICAL LOCK COMPULSORY TO ENSURE LOCKING OF THE LEAF WHEN CLOSING
CARDIN ELECTRONIC PROGRAMMER TO BE ORDERED SEPARATELY T600
GEARMOTOR FOR SWING GATES
BLADE3REV
230V
TECHNICAL FEATURES:
POWER SUPPLY: 230Vac
ABSORPTION: 1,6A
ABSORBED POWER: 370W
PUSH: 1900N
SCREW STROKE: 350mm
WORKING INTERMITTENCE: 30%
90° OPENING TIME: 18sec
MAXIMUM OPENING: 110°
DEGREE OF PROTECTION: IP44
