FAAC - GEARMOTOR 230V FOR SLIDING GATES WITH LEAF WEIGHT MAX. 400KG.
- RENEWED GEARMOTOR WITH INTEGRATED E781 ELECTRONIC CONTROL BOARD FEATURING ADJUSTABLE SPEED CONTROL LEVELS
- INCLUDES TWO DEDICATED INPUTS FOR SAFETY EDGES (NC OR 8.2 KOHM)
- NEW RETROACTIVE MOTOR CONTROL WITH HIGH-RESOLUTION ENCODER
- COMPATIBLE WITH SIMPLY CONNECT AND THE NEW FDS RADIO TECHNOLOGY
- PINION Z20 MODULE 4.
FAAC - 746 C Z20
109746
TECHNICAL FEATURES:
MAINS SUPPLY VOLTAGE: 220-240V - 50/60 HZ
MAX. POWER: 150W
PINION: Z20 MODULE 4
MAX. THRUST FORCE: 665N
MAX. LEAF WEIGHT: 400KG
MAX. LEAF SPEED: 12M/MIN
MAX. LEAF LENGTH: 50M
STOPPING SPACE: 30MM
DEGREE OF PROTECTION: IP44
STARTING CAPACITOR: 12,5 µF
OPERATING AMBIENT TEMPERATURE: -20° ÷ +55°.
THERMAL PROTECTION:120° SELF-RESTORING
ELECTRONIC EQUIPMENT: E781 BUILT-IN.
