FAAC - ELECTROMECHANICAL GEARMOTOR, FOR SLIDING GATES WEIGHING UP TO 500 KG PER LEAF
- E781 ELECTRONIC EQUIPMENT INTEGRATED IN AUTOMATION
- ADVANCED GEARMOTOR: INTEGRATED CONTROL UNIT WITH ADJUSTABLE SPEED
- HIGH PERFORMANCE MOTOR CONTROL
- EQUIPPED WITH HIGH-RESOLUTION MAGNETIC ENCODER FOR SMOOTH OPERATION
GEARMOTOR 740 C
109600
230Vac
TECHNICAL FEATURES:
Max. power: 430 W
Max. torque: 18 Nm (*)
Max. thrust: 450 N (*)
Reduction index: 1:25
Max. leaf width: 15 m
Leaf speed: 12 m/min
Limit switch: Magnetic
Pinion: Z16 module 4
Encoder: Magnetic encoder
Force regulation: Via electronic board
Ambient operating temperature: -20°c ÷ +55°c (**)
Thermal protection: 140°c self-restoring
Degree of protection: ip44
Frequency of use: 55 cycles/h
Release device: Rotary release knob - coded key
Starting capacitor: 10 μf
