GENIUS - IRREVERSIBLE AUTOMATIC BARRIER WITH ENCODER AND LYNX 08 INTEGRATED
BAR UP TO 7m (NOT INCLUDED)
AUTOMATIC ROD BALANCING BY MEANS OF 1 OR 2 SPRINGS OF YOUR CHOICE
LUMINOUS WARNING BEACON FOR BARRIER HOUSING
ERGONOMICALLY POSITIONED AND EASILY ACCESSIBLE CONTROL PANEL
EQUIPPED WITH ENCODER FOR OBSTACLE DETECTION
USER-FRIENDLY ROTARY RELEASE WITH CUSTOMISED KEY
CERTIFIED FOR CONTINUOUS USE FOR MORE THAN 1.000.000 OPERATIONS
ACCESSORIES NOT INCLUDED
ROD AND FOUNDATION PLATE NOT INCLUDED
RAINBOW 724 C 6130035
24V
TECHNICAL DETAILS:
- POWER SUPPLY (V): 230/115
- ELECTRIC MOTOR (V): 24
- MAXIMUM STARTING POWER (W): 480
- RATED MOTOR POWER (W): 220
- MAX. TORQUE AT 24VDC (NM): 370
- NOMINAL OPERATING TORQUE (NM): 140
- NOMINAL OPEN/CLOSE TIME (SEC)¹: DA 7 A 11
- OPERATING FREQUENCY AT 20°C: 70%
- OPERATING TEMPERATURE (°C): -20 +55
- NOISE (DBA): >70
- DEGREE OF PROTECTION: IP54
- OPERATOR WEIGHT (KG): 72
Complementary accessories (not included):
- 6100294: Foundation plate
- 6100201: Kit of 6 GENIUS logo stickers
