GENIUS -KIT FOR GATES WITH TWO SWING LEAVES UP TO 4 m OF WIDTH, COMPLETE WITH ACCESSORIES
- GEARMOTOR WITH EASY-TO-USE RELEASE LEVER
- INTERNAL KINEMATIC MOTION INCLUDING A BRONZE CROWN GEAR AND A STEEL WORM GEAR
- OPENING AND CLOSING SLOW MOTION
- OPTIONAL ROD COVER
- FREQUENCY 868 MHz - JLC
KIT G-BAT 868 MHZ 51701381
230V AC
IT INCLUDES:
- 1 6170030: Right actuator for g-bat 230v swing gates, up to 4 m per leaf
- 1 6170031: Left actuator for g-bat 230v swing gates, up to 4 m per leaf
- 1 6100328: Brain19 control unit 230v for swing gates
- 1 JA320: Control unit cover
- 1 6100332: 2-channel remote control kilo tx 2 868 mhz
- 1 6100147: Vega bus photocells
- 1 6100347: Frequency module rqfz 868 MHz
- 1 6100315: Guard 230v led flashing lamp
- 1 JA31101: Quick 1 key-operated selector
- 1 Gate Sign
MOTORS TECHNICAL DETAILS:
- POWER SUPPLY (V) 230
- ELECTRICAL MOTOR (V) 230
- NOMINAL POWER (W) 280
- CURRENT (A) 1.2
- THERMAL PROTECTION (°C) 140
- CAPACITOR (ΜF) 8
- THRUST (DAN) 350
- TORQUE (MM) 400
- MAX. SPEED (CM/SEC.)¹ 1.6
- OPERATING FREQUENCY AT 20°C S3 - 30%
- OPERATING TEMPERATURE (°C) -20 +55
- DEGREE OF PROTECTION IP54
