GENIUS - 24V IRREVERSIBLE ELECTROMECHANICAL GEARMOTOR FOR SWING GATES FOR CONDOMINIAL USE, UP TO 3 m PER LEAF
- PATENTED ENV FUNCTION (VIRTUAL NOMINAL ENCODER)
- SLOWDOWN IN OPENING AND CLOSING PHASES
- SUITABLE FOR RESIDENTIAL USE
- SAFETY PROCODER WITH BRAIN19 AND BRAIN15 BOARD
- RELEASE WITH LEVER AND ACCESS WITH PERSONALISED KEY
- INTERNAL KINEMATIC MECHANISM CONSISTING OF BRONZE CROWN GEAR AND STEEL WORM GEAR
- HORIZONTAL CABLE OUTLET FACILITATING INSTALLATION CLOSE TO THE GROUND
- DOUBLE-LAYER PAINTED ALUMINIUM BODY FOR INCREASED DURABILITY
MISTRAL T324 ENV
6170178
24V DC
TECHNICAL DETAILS:
POWER SUPPLY (V) 230
ELECTRIC MOTOR (V) 24
NOMINAL POWER (W) 35
CURRENT (A) 3
THERMAL PROTECTION (°C) -
CAPACITATOR (ΜF) -
THRUST (DAN) 150
STROKE (MM) 300
MAX. SPEED (CM/SEC.) 2.1
FREQUENCY OF USE AT 20°C CONTINUOUS
OPERATING TEMPERATURE (°C) -20 +55
DEGREE OF PROTECTION IP54
WEIGHT (KG) 7.5
