GENIUS - 230V REVERSIBLE ELECTROMECHANICAL GEARMOTOR FOR SWING GATES FOR RESIDENTIAL APPLICATION, UP TO 4 M PER LEAF
-SLOWDOWN IN OPENING AND CLOSING PHASES
- HORIZONTAL CABLE OUTLET FACILITATING INSTALLATION CLOSE TO THE GROUND
- DOUBLE-LAYER PAINTED ALUMINIUM BODY FOR INCREASED DURABILITY
- COMBINED WITH BRAIN19/BRAIN15 BOARD IT IS POSSIBLE TO USE THE SAFETY PROCODER
MISTRAL 400 R
6170047
230V AC
TECHNICAL DETAILS:
POWER SUPPLY (V) 230
ELECTRIC MOTOR (V) 230
NOMINAL POWER (W) 300
CURRENT (A) 1.3
THERMAL PROTECTION (°C) 140
CAPACITATOR (ΜF) 6.3
THRUST (DAN) 280
STROKE (MM) 400
MAX. SPEED (CM/SEC.) 1.6
FREQUENCY OF USE S3 - 30%
OPERATING TEMPERATURE - 10 + 55
DEGREE OF PROTECTION IP54
WEIGHT (KG) 8
