GENIUS - ELECTRONIC BOARD FOR ONE OR TWO 24VDC / 230VAC SWING GATE GEARMOTORS.
- EASY INSTALLATION VIA DISPLAY AND BUTTONS, WITH CONFIGURABLE PARAMETERS FOR FORCE, SPEED AND SLOWDOWN
- LOW POWER CONSUMPTION DUE TO XLC MODULE THAT REDUCES STANDBY CONSUMPTION TO 0.5W
- MOTOR CONTROL WITH BUILT-IN VIRTUAL ENCODER OPTIMIZES FORCE AND SPEED BY DETECTING OBSTACLES WITH ADJUSTABLE SENSITIVITY
- WITH XUSB DEVICE ALLOWS RAPID FIRMWARE UPDATES VIA USB STICKS
- COMPATIBLE WITH ALTERNATIVE ENERGY SOURCES SUCH AS SOLAR PANELS.
GENIUS - BRAIN 20
6100362
24 VDC - 230 VAC
TECHNICAL FEATURES:
POWER SUPPLY VOLTAGE (VAC): 220 - 240 50/60HZ
MAXIMUM POWER: 350W
STANDBY POWER: 4.4W
STAND-BY POWER WITH XLC MODULE: 0.5W
MAX ELECTRIC MOTOR VOLTAGE: 24V
MAX MOTOR POWER: 340W (170W FOR MOTOR)
MAX FLASHING LIGHT LOAD: 24V
FUSE PROTECTION: F 2.0A-250 V
PROTECTION CLASS: IP54
OPERATING TEMPERATURE: -20°C + 65°C
