NOLOGO - 230VAC CONTROL UNIT/CONTROL PANEL FOR SLIDING MOTOR/OVERHEAD MOTOR/GARAGE DOOR/SECTIONAL DOOR.
- THE 433.92MHZ RADIO RECEIVER IS INTEGRATED WITH FIXED CODES AND ROLLING-CODE HCS MANAGEMENT.
- INPUTS: START-CLOCK, CLOSE, PEDESTRIAN, PHOTO ON CLOSING, LIMIT SWITCH OPEN AND CLOSE, STOP, PHOTO-TEST.
- THREE-WIRE ENCODER AND MAN-PRESENT FUNCTION.
- THE SLOW DOWN SPEED, LOCK AND FORCE ARE ADJUSTABLE.
- WORKING TIMES ARE IN 'REAL-TIME'.
- BOARD ONLY, EXCLUDING BOX.
- IBR-N RECEIVER NOT INCLUDED.
NOLOGO
START-S8BL
TECHNICAL FEATURES:
- POWER SUPPLY: 230VAC
- MAXIMUM MOTOR POWER: 750W 4A
- DRY CONTACT: 5A
- CONSUMPTION: 24VAC/DC 300MA, 12VDC 50MA
- WEIGHT (GR): 624
- SIZE (MM): 149X87X45.
