VORTICE - PORTABLE THERMOVENTILATOR, CALDORÉ SERIES
• FRONT AND REAR PANELS, TOP AND BOTTOM GRILLES MADE OF STEEL WITH SCRATCH-RESISTANT PAINT FINISH, COLOUR GREY.
• FLANKS MADE OF SELF-EXTINGUISHING PLASTIC RATED V0, COLOUR GREY.
• 3-SPEED SHADED POLE MOTOR WITH THERMAL OVERLOAD PROTECTION, SHAFT TURNING IN SELF-ALIGNING AND SELF-LUBRICATING BUSHINGS AND COUPLED TO A CENTRIFUGAL ROTOR MOULDED FROM THERMOPLASTIC RESIN.
• HEATING ELEMENT PROTECTED BY LIMITER WITH PTC SENSOR, MANUAL RESET.
• LUMINOUS SWITCHES FOR ON/OFF CONTROL AND SELECTION OF THE 3 HEAT OUTPUT SETTINGS (800/1200/2000 W).
• MANUALLY ADJUSTABLE ROOM THERMOSTAT WITH ANTIFREEZE FUNCTION GUARANTEEING AUTOMATIC ACTIVATION OF THE HEATER WHENEVER AMBIENT TEMPERATURE DROPS BELOW 5 °C.
• ADJUSTABLE 24-HOUR TIMER FOR PROGRAMMING ON AND OFF PERIODS, MINIMUM DIVISIONS OF 15’.
• PVC POWER CORD WITH MOULDED PLUG.
• BUILT-IN RECOIL CORD WINDER.
• 4 STABILIZER FEET WITH SPECIAL NON-SLIP RUBBER PADS.
• IMQ SAFETY CERTIFICATION.
CALDORÉ RT TIMER 70221
ABSORBED CURRENT MAX (A): 8,7
ABSORBED POWER MAX (W): 2000
FREQUENCY (HZ): 50
INSULATION CLASS: II°
MAX. ABSORBED POWER AT MAX SPEED (W): 2000
VOLTAGE (V): 230
WEIGHT (KG): 5,3
SIZE A (MM): 685
SIZE B (MM): 415
SIZE C (MM): 200
SIZE D (MM): 100
